Vertical Water Level Sensor Float Switch Liquid Level Switch Stainless Steel

$16.26

Tax included. Shipping calculated at checkout.

Description:

- Multi-point control is available, and the control switch can be customized with the liquid level position.
- The reed switch does not need to be powered separately.
- High reliability, low wiring cost and easy installation.
- The junction box has complete specifications, such as aluminum alloy, plastic, stainless steel and other materials.
- The finished material is made of stainless steel 304, which can be used in high temperature and high pressure places.
- Junction box protection grade IP-65 or above.
- This product can be applied to liquids with different densities, different acids and bases, different pressures and temperatures.

Specifications:

Working voltage: 0-220 (V)
Working current: 1 (A)
Material: 304 Stainless Steel
Working temperature: -30-120 (°C)
Maximum temperature resistance: 150 (°C)
Working pressure: 1.6 (Mpa)
Maximum withstand voltage: 1.6 (Mpa)

Technical Parameters:

Low pressure:
1. Contact capacity: 10W/SPST
2. Switching current: 0.5A
3. Switching voltage: 100VDC
4. Contact resistance:<100mΩ
5. Electrical life: 1 million times
6. Working temperature: -30 ° C ~ 80 ° C
High pressure:
1. Contact capacity: 50w/SPST
2. Switching current: 1.5A
3. Switching voltage: 220VAC
4. Contact resistance:<100mΩ
5. Electrical life: 1 million times
6. Working temperature: -30 ° C ~ 80 ° C

Package including:

1 × Water Level Switch
